| The following software can be downloaded. |
| |
|
| Overall Procedure for Software
Download and Installation |
| |
1. |
Select and click the software you want to download
from the list. |
| |
2. |
Go to the folder where the downloaded file
was saved.. |
| |
3. |
Click to decompress and install the downloaded
file. |
| |
For the software marked with (*), perform the following operations at startup. |
| |
4. |
Right-click the software, and then click Run as administrator. |
| |
|
|
| |
|
|
| Software for Download |
|
| Console
software |
| Software name |
Applicable
model |
Capacity |
Update date |
ACD, ACR-13A (15A) console software
SWS-AC001M_V107
|
ACD-13A
ACR-13A
ACD-15A
ACR-15A |
33,916 KB
|
2019.06.04
|
ACS-13A console software (*)
SWS-ACS01M_V300
|
ACS-13A |
8,754 KB |
2015.07.31 |
BCx2 series console software
SWC-BCx01M_V105
|
BCx2 series |
61,652 KB
|
2016.05.09 |
PCA1 console software
SWC-PCA101M_V100
|
PCA1 |
61,056 KB
|
2019.12.24 |
PCB1 console software
SWC-PCB101M_V101
|
PCB1 |
55,374 KB
|
2021.02.24 |
QTC1 console software
SWC-QTC101M_V203
|
QTC1-2
QTC1-4 |
1333,356 KB |
2021.08.26 |
QMC1 console software
SWC-QMC101M_V102
|
QMC1 |
58,541 KB |
2021.08.23 |
SAAP, SAVP console software (*)
SWS-SAx02M_V104
|
SAAP, SAVP |
6,636 KB |
|
SE series console software (*)
SWS-SE001M_V106
|
SE series |
29,068 KB |
|
SG, SH series console software
SWC-SGSH01M_V203
|
SG, SH series |
58,125
KB
|
2020.01.06 |
SIF-600 console software
SWC-SIF01M_V104
|
SIF-600 |
29,254
KB |
2019.01.10 |
WCL-13A console software
SWS-WCL01M_V117
|
WCL-13A |
40,496
KB
|
2019.12.20 |
| Monitoring
software |
| Software name |
Applicable
model |
Capacity |
Update date |
ACD, ACR-13A/15A monitoring software
SWM-AC001M_V105
|
ACD-13A
ACR-13A
ACD-15A
ACR-15A |
32,342 KB |
2019.06.06 |
|
ACS-13A monitoring software (*)
SWM-ACS01M_V201
|
ACS-13A |
9,992 KB |
2017.06.13 |
|
BCx2 series monitoring software
SWM-BCx201M_V103
|
BCx2 series |
59,321
KB |
2018.09.13
|
HR-706 monitoring software (*)
SWM-HR001E_V104
|
HR-706 |
8,441 KB |
|
JCx-33A (DCL-33A) monitoring software(*)
SWM-JC001M_V120
|
JCD-33A
JCR-33A
JCM-33A
JCS-33A
DCL-33A |
23,802 KB |
|
JCL-33A monitoring software
SWM-JCL01M_V103
|
JCL-33A |
16,577
KB |
2019.06.04 |
JIR-301-M monitoring software (*)
SWM-JIR01M_V201
|
JIR-301-M |
49,024
KB |
2018.08.31 |
PC-900 monitoring software (*)
SWM-PC001E_V120
|
PC-935
PC-955
(*1) |
9,491 KB |
|
PCA1, PC-900 monitoring software (*)
SWM-PC002M_V100
|
PCA1
PC-935
PC-955
(*2) |
11,545
KB |
|
PCA1 monitoring software
SWM-PCA101M_V100
|
PCA1
(*3) |
56,694 KB |
2019.06.11 |
PCB1, PCD-33A monitoring software (*)
SWM-PCD01M_V200
|
PCB1
PCD-33A
(*4)
|
8,686
KB |
2017.10.11 |
PCB1monitoring software (*)
SWM-PCB101M_V102
|
PCB1
(*5) |
52,527KB |
2021.02.24 |
|
THT-500 monitoring software
SWM-THT01M_V101
|
THT-500 |
48,644
KB
|
2018.09.28 |
WCL-13A monitoring software (*)
SWM-WCL01M_V107
|
WCL-13A |
35,171 KB |
|
(*1) Available only for PC-900.
(*2) Available for both PC-900 and PCA1.
To use for the PCA1, C5
option is not required,
however, only 10-patterns,
10-steps can be displayed.
(*3) Available only for PCA1.
To use this software,
the C5 option should be ordered for PCA1.
(*4) This monitoring software is common to both PCD-33A and PCB1.
As the number of patterns
and steps of PCD-33A are different from
those of PCB1, Pattern
10 and Step 10 of each pattern of PCB1 are
not available for the
software.
If the PCB1 is connected,
do not set anything to Pattern 10 and
Step 10 of each pattern.
(*5) Available only for PCB1.
| Setting
software |
| Software name |
Applicable
model |
Capacity |
Update date |
Setting software
SWS-00001M_V103
(Windows 7/8/10)
|
ACS-13A
BCx2 series
DCL-33A
JC series
NCL-13A |
6,281 KB |
|
| GSD
file |
| Software name |
Applicable
model |
Capacity |
Update date |
IFP-100 GSD file
SHIN052E.gsd
|
IFP-100 |
3 KB |
|
Shinko software below is not compatible
with 64-bits OS.
| Monitoring
software |
| Software name |
Applicable
model |
Capacity |
Update date |
C series monitoring software (*)
SWM-CC002E_V205
|
C series |
17,578 KB |
|
FCx-13A monitoring software (*)
SWM-FC003E_V108
|
FCD-13A
FCR-13A
FCR-23A
FCS-23A |
6,878 KB |
|
FCL-100 monitoring software (*)
SWM-FCL01M_V100
|
FCL-100 |
27,588 KB |
|
FIR-201-M monitoring software (*)
SWM-FI001E_V105
|
FIR-201-M |
3,592 KB |
|
LMD-100 monitoring software (*)
SWM-LMD01M_V103
|
LMD-100 |
29,512
KB |
|
NCL-13A monitoring software (*)
SWM-NCL01M_V102
|
NCL-13A |
23,276
KB |
|
|
| |
Please download "WinHlp32.exe"
on Windows Vista, Windows 7 and Windows 8 |
|
The monitor software Help file may not displayed on
Windows Vista, Windows 7 and Windows 8.
If the Help file cannot be displayed, please install the 'Windows
Help'.
Windows Help (WinHlp32.exe) is a help program which has been included
in Microsoft windows since Microsoft Windows 3.1 OS.
However, it is not included in Windows Vista OS or above.
To display the Help file, please download "WinHlp32.exe" from the
Microsoft download center.
Windows
Help program (WinHlp32.exe) for Windows Vista
Windows
Help program (WinHlp32.exe) for Windows 7
Windows
Help program (WinHlp32.exe) for Windows 8 |
|
